Sanlorenzo Sl 100

Caratteristiche principali

Tipologia

Fly Bridge

Omologazione

-

Visibile

-

Anno costruzione

2007

Lunghezza

29.10 metri

Larghezza

6.80 metri

Immersione

0.00 metri

Materiale scafo

-

Materiale coperta

-

Materiale sovrastruttura

-

Portata persone

-

Cabine

-

Posti letto

-

Bagni

-

Bandiera

-

Certificato di sicurezza

-

Motorizzazione e impianti

Carburante

Diesel

N° motori

2

Produttore

MTU

Modello

-

Potenza

2185 HP

Trasmissione

Linea d'asse

Ore di moto

-

Capacità carburante

12200 litri

Generatore

1 x 540 kw 2 X 27 KW KOHLER

Dissalatore

-

Velocità crociera

20 nodi

Velocità massima

25 nodi

Consumo

-

Autonomia

-

A TIMELESS MASTERPIECE: MASTER CABIN ON THE MAIL DECK! IN COLLABORATION WITH KK SUPERYACHTS!

Interni

4 CABINS, 8 OWNER AND GUESTS.
3 CREW CABINS, 5 CREW.
CABINS: 1 Master, 1 VIP, 1 Double, 1 Twin.

GALLEY:
Miele dishwasher
Miele fridge
Nespresso coffee machine
Moulinex kettle
Rowenta toaster
Wine cellar
Miele microwave
Alpes extractor
Miele electric stove
Miele oven
Frigonautica fridge
Dyson vacuum cleaner

LAUNDRY:
Miele washing machine
Miele dryer
Miele microwave
Calor iron

CREW MESS:
TEAC amplifier
Samsung TV
Liebherr freezer
Dyson vacuum cleaner
2 x Electrolux mini vacuum
Frigonautica fridge

AUDIO / VISUAL ENTERTAINMENT SYSTEMS
KVH Satellite TV system.
Salon fitted with Samsung TV and Bose sound system with FTA satellite receiver
Owners cabin Samsung TV and Bose sound system
Forward guest staterooms Samsung TV
Aft VIP Samsung TV

Strumentazione di bordo

RADAR: Raymarine 4ft open scanner with output to M1500 screen on port side, and control pad.
CHART PLOTTER: Raymarine chart plotter, part of the integrated Raymarine system. (Second E120 screen stbd side).
WIND INSTRUMENT: Raymarine anemometer
MFD: Raymarine multifunction instruments at bridge, also at upper steering position.
GNSS: One Raymarine GPS smart antenna connected to the Raymarine system.
STANDARD COMPASS: Riviera SRL Genoa ‘White Star’ 6-inch compass.
ECHO SOUNDER: Raymarine digital sounder. Dual frequency 200Khz and 50Khz
VHF /DSC: One Raymarine Ray 240E
INMARSAT C: Sailor 6110 series Standard C
NAVTEX: Furuno NX 700
MF/HF/ SSB: Furuno FS 2571C
EPIRB: Sailor E5 Smartfind 406 Cat 1 EPIRB
Battery expiry date 09/2022, Serial No: 100-05279, HRU expiry date April 2020
SARTS: One ACR Pathfinder 3 SART, battery expiry 09/2022
GMDSS VHF HANDSETS: One Icom IC-GM1600E GMDSS handheld VHF
One spare lithium battery expiry 09/2022.

FLY DECK NAV EQUIPMENT:
VHF: RAY 249E VHF
CHART PLOTTER: Raymarine E120 screen
MFD: Ray ST290 MFD
AUTOPILOT: Ray ST 290 Autopilot
WIND INSTRUMENT: Ray ST290 Wind
2nd handset for Raymarine
Analogue main engine instrumentation
Rudder angle indicator
Bow and Stern thrusters’ control
Battery paralleling switch
Steering selection switch
Port and Starboard anchor inch raise/lower

Dotazioni e armamento

AIR CONDITIONING: Condaria, 55,000 Btu /Hr per compressor
BILGE PUMPS: - 24Vdc Bilge pumps with alarms in each bilge space
- 220Vac Gianneschi ACM 501BT multistage centrifugal 1.5-inch bilge pump
STABILISERS: CMC Marine - Underway & at anchor
BILGE TANK: - 1 x forward tank with level sensor and vent
- Deck filler with pre filters
BOILERS: 2 x hot water boilers
PRESSURE PUMPS: - 3 x Gianneschi water pressure pumps, one is DC.
- 2 x 1.5 Kw water heaters
WATERMAKER: Idromar
GENERATOR: 2 x Kohler 27 kW (John Deere) AC 3 Phase (400V) 50 Hz
SHORE POWER: 1 x Connection 65 amps
AC POWER: 230V - 50Hrtz
DC: 24VDC
BATTERIES: Main engine and generator start batteries, MTU supply batteries.
Service batteries in port side aft 12 x 2V traction batteries.
CHARGERS: Three Mastervolt 24V 100-amp chargers port side
One Mastervolt 24V 25A
One Dolphin 24V 20A
ANCHOR WINDLASS: 2 x Maxwell 4500 fitted with warping drums and chain locks
ANCHOR: 2 x HHP -115Kg anchors
2 x Lengths of 14mm – 125m of galvanised chain
PASSERELLE: Aft hydraulic gangway
CAPSTAN: 2 x aft deck
LAUNCH SYSTEM: Tender and jet ski launch system in garage.
FLY DECK: Helm station, Bar, Bimini roof

THRUSTER BOW / STERN: BSC
Two 3 phase steering pump motors
Actuators attached to the rudder stocks
Rudder angle display
Emergency hand steering in garage
Ray marine autopilot
Trim tabs

FIRE FIGHTING EQUIPMENT
The vessel is fitted out with FFE equipment.
One Gianneschi ACM 501BT multistage centrifugal 1.5-inch fire pump
One diesel emergency pump in forward deck locker.
220Vac fire pump in aft technical space

TENDERS & WATERSPORTS EQUIPMENT
Lomac tender 310LX (3.45 x 1.61m)
Jetski Seadoo Spark
